1X8/ 1x16 Fiber Optic Splitter With SC/UPC Connector / PLC Splitter Module ( Insert Type )

Product Categories

TTI Fiber Communication Tech. Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Brand Name : TRT

Model Number : 1x8 Splitter module

Certification : ISO9001

Place of Origin : Guangdong,China

MOQ : Negotiable

Price : Negotiable

Payment Terms : T/T, , paypal

Supply Ability : 5000pcs/day

Delivery Time : 3-5working days

Packaging Details : in pp bag

connector : SC/UPC

Wavelength : 1310/1550nm

Cable : 0.9mm

Length : 0.5m,1m or as customzied

Contact Now

1X8/ 1x16 PLC Splitter Module (Insert type) with SC/UPC connector

Feature :

Low Excess loss

Various Coupling Ratio

Environment stable

Single mode and multi mode available

Application:

Long-haul Telecommunications

CATV Systems & Fiber Optic Sensors

Fiber Optic communication system

Local Area Network

Specification:

Parameters	1×2	1×4	1×8	1×16	1×32
Operating Wavelength (nm)	1310/1490/1550
Fiber Type	G657A1 or customer specified
Insertion Loss (dB)(P/S Grade)	3.8/4.0	7.1/7.3	10.2/10.5	13.5/13.7	17/17.4
Loss Uniformity (dB)	0.4	0.6	0.8	1.2	1.5
Polarization Dependent Loss(dB)	0.2	0.2	0.2	0.25	0.3
Return Loss (dB) (P/S Grade)	55/50	55/50	55/50	55/50	55/50
Directivity (dB)	55	55	55	55	55
Wavelength Dependent Loss (dB)	0.3	0.3	0.3	0.5	0.5
Temperature Stability (-40~85 ℃)(dB)	0.4	0.4	0.4	0.5	0.5
Operating Temperature (℃)	-40~85
Storage Temperature (℃)	-40~85
Device Dimension (mm)	40×4×4	40×4×4	40×4×4	50×4×4	50×7×4
Module Dimension (mm)	100×80×10	100×80×10	100×80×10	120×80×18	140×115×18
Mini-Module Dimension (mm)	50×7×4	50×7×4	50×7×4	60×12×4	80×20×6

Packing and Shipping :

1X8/ 1x16 Fiber Optic Splitter With SC/UPC Connector / PLC Splitter Module ( Insert Type )
